Technical data
System angle
0° to 30° depending on requirements (typically 15°), can be mounted in south and east/west orientation
Module
configuration
Max. 4 vertical / 8 horizontal (typically: 3 vertical/6 horizontal)
Module types
For framed modules with typical frame heights of 30-45 mm
Table length
Any – Compensation for longitudinal thermal expansion of module girders enables endless assembly
Foundation
Pile-driven post profiles without any additional foundations, the required pile-driving depth depends on the subsoil
Post spacing
Depends on the system configuration (number and orientation of modules, system angle, snow and wind loads)
Typically: 2-4 m table length
Materials
Profile system made of S350GD+Z600/Z450 or ZM310/ZM250 or comparable, stainless steel connecting elements
Adjustment options
Multiple perforated connection points allow limited compensation of inaccuracies in pile-driving depth and position
Structural analysis
In the case of a quotation: Pre-dimensioning to determine the material requirements
In the case of an order: Project-specific, tested structural calculation according to Eurocode EN 1090
Field of application,
requirements
Subsoil that can be pile-driven and is capable of load-bearing
The system is suitable for wind and snow load zones 1-4
Optional accessories
Slope compensation piece: For mounting the module girders on slopes of up to 10° in the table’s longitudinal direction
Additional posts / profiles for mounting inverters or profile variants with custom perforations, for example
Warranty
10 years
Tested
EN 1090, ISO 9001, CE-compliant
